Description

Brushed Crawler Motor/ESC Combo, 35T: 3.5mm Bullet, EC3

Overview

This Dynamite® brushed crawler motor/ESC combo offers price sensitive enthusiasts the perfect arrangement for their crawlers. Additionally, the system is a great completion item for both kits and rollers. The combo includes a powerful, rebuildable 540 size 35 turn motor and a waterproof, NiMH/LiPo compatible, brushed ESC offering forward/brake/reverse, forward/brake and crawler drive modes. Additionally, it features “On the Fly” adjustable drag brakes with specific 3 channel radios. Its compatibility makes it an ideal replacement ESC or the perfect upgrade to your current non-LiPo, non-waterproof, or limited motor spec ESC. As with all Dynamite power systems, motors and ESC’s are available separately.

Component Specifications

Motor:

• Motor dimensions:  36mm dia x 53mm L
• Shaft dimensions:  1/8”/3.12mm x 12.5mm
• Input voltage limit:  2S-3S LiPo/6-9cell NiMH
• Bearings/Bushings:  Ball bearings

ESC:

• Input Voltage:  2-3S LiPo, 6-9 Cells NiMH/NiCd
• Size:  46.5x34x28.5mm
• Weight:  68g
• Motor Limit:  >12T 2S/ >18T 3S
• On-Resistance FET:  .002
• Continuous current:  40A
• Rated/Peak Current:  180A
• Braking Current:  90A
• BEC Voltage:  6.0V 3.0A Peak
• Connector:  IC3
• PWM Frequency:  1KHz

Adjustable Timing Yes

Battery Connector IC3

Bearings or Bushings Rubber sealed ball bearings

BEC Yes

BEC Continous Current 6V/3A

BEC Type Shared between receiver, auxillary light ioutput and cooling fan

BEC Voltage 6V

Brakes Electronic

Cells 2S – 3S LiPo, 6 – 9 cell NiMH

Connector Type 3.5mm Bullet, 3.5mm Tamiya style bullet, IC3

Forward Yes

Height ESC 1.1″ (28.5mm)

Input Voltage 7.2 – 11.1V

Length ESC 1.8″ (46.5mm)

Motor Connector 3.5mm Bullet

Motor Type Brushed, Brushed 3-slot rotor, open endbell for 1:10 scale rock crawlers

Overall Diameter 1.4″ (36mm)

Overall Length 2.1″ (53mm)

Reverse Yes

Shaft Diameter 1/8″ (3.2mm)

Size Motor 2.1 x 1.4″ (53 x 36mm)

Turns 35T

Type 1/10 scale crawler

Weight ESC 2.4oz (68g) with wires

Width ESC 1.3″ (34mm)
